Yokohama Floating Ship Fender Pneumatic Boat Marine Rubber Fender
In order to produce the qualified and famous China Brand of
pneumatic fenders , FL RUBBER invested the advanced production and
test equipments, and invited the foreign experienced engineers of
pneumatic fenders, which ensure all FL pneumatic fenders are
manufactured comply with ISO17357:2002. Therefore, FL-RUBBER is the
unique manufacturer of ISO17357 qualified Pneumatic Fenders in
China.
In order to protect your maritime values, FL-RUBBER strongly
recommends the use of ISO certified Pneumatic Fenders while
performing the high quality needed for safe berthing during ship to
ship operations involving bunkering or discharging of oil or gas,
and ship to port operation
Advantages of FLmarine rubber fender:
* Absorb more energy,less reverse impact on the ships
* More flexible ,easy installation
* Long term service life
* Not being bent out of shape under pressure
* Good quality have been checked by many buyers
* Optional tire and chain,can provide chain with hot galvanizing or
stainless steel(304,312,316)
* Optional end fittings for the better suitable of applications
Application of FL rubber fender:
FL pneumatic rubber fender has widespread application as following:
* Ship to ship,ship to wharf
* Oil tankers, container vessels
* Luxury yachts, ocean platforms
* Larges shipyards
* Fender system
* Military ports ,warship
* Larger under water foundations of bridges, etc.
Technical performance of marine rubber fender
Specification DXL(m) | 0.05Mpa(Initial pressure 0.05Mpa) | (Initial pressure 0.08Mpa) |
| Weight(kg) | Reaction force(KN) | GEA (KJ) | Weight (kg) | Reaction force(KN) | GEA (KJ) |
| 0.5X1.0 | 25 | 674 | 6 | 25 | 85 | 8 |
| 0.6X1.0 | 32 | 74 | 8 | 32 | 98 | 11 |
| 0.7X1.5 | 50 | 137 | 17 | 50 | 180 | 24 |
| 1.0X1.5 | 80 | 182 | 32 | 80 | 239 | 45 |
| 1.0X2.0 | 100 | 257 | 45 | 125 | 338 | 63 |
| 1.2X2.0 | 120 | 297 | 63 | 165 | 390 | 88 |
| 1.35X2.5 | 165 | 427 | 102 | 226 | 561 | 142 |
| 1.5X3.0 | 315 | 579 | 153 | 370 | 761 | 214 |
| 1.7X3.0 | 405 | 639 | 191 | 436 | 840 | 287 |
| 2.0X3.5 | 590 | 875 | 308 | 632 | 1150 | 430 |
| 2.5X4.0 | 1050 | 1381 | 663 | 1110 | 1815 | 925 |
| 2.5X5.5 | 1333 | 2019 | 943 | 1410 | 2653 | 1317 |
| 3.0X5.0 | 1880 | 2000 | 1050 | 2155 | 2709 | 1571 |
| 3.0X6.0 | 2160 | 2488 | 1312 | 2470 | 3292 | 1888 |
| 3.3X4.5 | 2020 | 1884 | 1175 | 2300 | 2476 | 1640 |
| 3.3X6.0 | 2300 | 2783 | 1675 | 2600 | 3652 | 2338 |
| 3.3X6.5 | 2700 | 3015 | 1814 | 3080 | 3961 | 2532 |
| 3.3X10.6 | 4403 | 5257 | 3067 | 5020 | 6907 | 4281 |
| 4.5X9.0 | 6554 | 5747 | 4752 | 7470 | 7551 | 6633 |
| 4.5X12 | 8739 | 7984 | 6473 | 9960 | 10490 | 9037 |
| Note:The weight is the fender body weight(without tires and
chain),with weight error of ±10% and counterforce error of ±10% |
Storage of FL rubber fender
* When not using for a long time,wash the surface of the fender,dry
up and fill in sufficient right amount of compressed air to lay
them in a cool.dry and well-ventilated place.
* The storage place of pneumatic rubber fender should be far away
from hear source
* Try to keep fender away from acid,alkali,grease and organic
solvents
* When not applying the fenders,the pneumatic rubber fender can’t
be piled up and heavy items can’t be piled on the fender
FAQ
Q1: What’s the material of your products?
A: Our raw material is natural rubber, and rubber-dipped nylon cord
fabric
Q2: Are you factory or trading company?
A: Qingdao Florescence Rubber Industry Co.,Ltd is the company and
factory,located in Jimo City,Qingdao,near to Qingdao port and
Qingdao airport,which is convenient for transportation.
Q3: How can I get samples from you?
A: We are honored to provide you samples for check
quality.Customers just confirm freight collect and then we could
send out the sample by FedEx,DHL,UPS,TNT and so on.
Q4: What’s certificates can your company provide?
A: We can provide CCS,ABS,DNV,LR,BV certificates.
