Introduction of heavy duty rubber launching balloon ship airbags

Ship rubber airbags, also called marine airbags, docking airbags, ship lauching balloons, marie air bags , now have become one convenient ship launching method in the some shipyards, especially where slipways are not available.

Qingdao Florescence is the first company that initiated airbags for ship launching in China from year of 1992. During the 20 years' development and experience in airbag production and ship launching, our ship launching airbags have become the most reliable.

Structure of ship landing rubber airbag

1) Outer Rubber Layer
The outer rubber layer that covers the outside of marine airbag to protect under layers from abrasion and other external forces. This compound has sufficient tensile and tearing strength to withstand any condition and hard usage.

2) Inner Rubber Layer
The inner rubber layer seals pressurized air inside marine airbags.

3) Synthetic-Tire-Cord Layer as Reinforcement
The reinforcement cord layers, which are made of synthetic-tire-cord commonly used in tires, are arranged at ideal angles to hold the internal pressure and distribute stress evenly. So they can provide strong efficient reinforcement.

Specification of ship landing rubber airbag

We usually produce and supply airbags in size of following as per customer's launching requirement:
Diameter: 0.8m-2.8m

Effective length: 5m-24m
Layers: 3-10 layers

Diameter	Effective Length	Layers with cord	Working Pressure	Lifting Height	Tons/Airbag
1.2m	10m	6	0.17MPA	0.9m	78.51tons
1.5m	12m	8	0.18MPA	1.2m	100.50tons
1.8m	15m	8	0.15MPA	1.5m	104.69tons
2.0m	18m	10	0.17MPA	1.5m	235.54tons
2.5m	18m	12	0.16MPA	2.0m	226.12tons

Features

1.High resistance to pressure: When marine airbag is put under the bottom of the ship, it is squeezed by the ship and the air. As a result of the uneven rotation rate, the airbag will change the spiral shape. Our products has high resistance to take the pressure to remain its shape.
2.Durable anti-aging and wear-resistant ability: Marine airbags are exposed to sunlight, fresh water, sand and other pollutants in a hard environment. Our products are durable in appearance, resistant to fresh water and chemicals, and resistant to aging.
3.Optimized layout: the strength model of inflatable airbag was established and the function test was conducted.

Advantages of marine rubber airbag

A.Saving the investment of shipyard construction
The construction of launching facilities, like traditional slideway and its underwater engineering, are very expensive.If using airbag launch, only a simple launching slip way shall be built without complex underwater engineering.
B.Simple operation,saving labor and work hours
Airbag launch avoids lots of trouble, such as the complex process of cleaning away the mucky soil on the surface of the slideway, covering or smearing with lubricating grease, setting slide plates and transoms and then binding them with hull, so as to save material consumption,manhour and expending time on preparation.Usually the preparation for airbag launch
maybe finished within one or two days due to the whole process is simple.The airbags may be reused by retrieving after
operatiion,that drops shipbuilding cost considerably.

C.Environmental friendly
Currently, countries in the world are highly regarded as an important act to promote environmental protection.

Factory established in 1992, Qingdao Florescence Marine Supply Co., Ltd (Subsidiary of Qingdao Florescence Co., Ltd) specializes in manufacturing pneumatic rubber fenders, foam fenders, various ship dock rubber fenders, and ship launching & salvage rubber airbags.

FLORESCENCE products are designed, manufactured, and tested by per ISO 9001:2015 requirements. And every unit is robustly built to the stringent requirements of ship surveyors such as CCS, BV, RS, ABS, LR, etc.

We are the supplier of many navy, such as Bangladesh Navy, France Navy, Greece Navy, Thailand Navy, Italy Navy, Philippines Navy, etc.

FLORESCENCE considers our clients as a part of the team, treating them as partners. We are always together with them on each step of the way, from finding the solutions of fender using and ship launching to the manufacturing and installation operations on site. Our rich experience has earned us a reputation as a dependable partner in many ports and shipyards around the world.
