Cylindrical Marine Rubber Airbag Length 5-24m For Ship Lifting Landing

Ask Lasest Price
Brand Name :	FLORESCENCE
Model Number :	NC1-1
Certification :	CCS,ABS,BV,LR,CCS BV GL
Price :	USD1000
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100pcs per month
Delivery Time :	5-15 days

Add to Cart

Product Details
Company Profile

Cylindrical Marine Rubber Airbag Length 5-24m For Ship Lifting Landing

Boat Rubber Air Bag Construction:
Reinforced Synthetic Tire-Cord Layer:
The boat rubber air bags are made with reinforced synthetic tire-cord layers which have a much better performance than air bags made with PVC coated fabrics.
High-Pressure Design:
The boat rubber air bags have a maximum working pressure of 0.25Mpa.
Holistic Screw Technology:
This method of manufacture ensures that there aren't any welded seams making for a stronger product than RF welded boat rubber air bags.

Cylindrical Marine Rubber Airbag Length 5-24m For Ship Lifting Landing

Details of ship launching airbags:

Name	ship launching airbags / marine airbags for vessel/boat/launch
Material	Natural rubber
Brand Name	Florescence
Characteristic	1. High strength 2. Wear resistance and anti-aging 3. Good air tightness 4. Safety and reliability 5. High kneading & compressing resistance and damping capacity
Certification	CCS,ABS,BV,DNV,ISO14409:2011
Price	excellent quality and competitive price
Packaging	wooden packing or upon customers requirement
Applicable for ship	1. ship launching and ship landing airbags
	2. rubber airbag for ship lifting,heavy lifting,caisson moving,upgrading,heavy building or constructions moving
	3. Standard ship airbag maximum diameter size range is 2.0m
	4.High-pressure ship launching marine airbags are used for ship launching, ship landing, ship lifting, loading, and floating.

Cylindrical Marine Rubber Airbag Length 5-24m For Ship Lifting Landing

Advantage

Our test the ship rubber airbags purchased based on the test items indicated below:
 * The appearance of the airbag is free from defects such as blemishes, bubbles, cracks, etc.
 * The diameter, length and working pressure of each air bag need to be tested before shipping.
 * The airtightness test of the airbag complies with the ISO 14409 standard. Air loss per hour does not exceed 5%

Ship Launching Bearing Capacity

Diameter	Working Pressure	Working Height	Guaranteed Bearing Capacity per Unit Length
m	MPA	m	kN/m	t/m	1b/ft
D=0.8m	0.25MPA	0.5m	117.92	12.02	8079
		0.4m	157.16	16.02	10768
		0.3m	196.49	20.03	13463
		0.2m	235.73	24.03	16151
D=1.0m	0.20MPA	0.6m	125.76	12.82	8617
		0.5m	157.16	16.02	10768
		0.4m	188.65	19.23	12925
		0.3m	220.04	22.43	15076
		0.2m	251.53	25.64	17233
D=1.2m	0.17MPA	0.7m	133.61	13.62	9154
		0.6m	160.3	16.34	10983
		0.5m	187.08	19.07	12818
		0.4m	213.76	21.79	14646
		0.3m	240.44	24.51	16474
		0.2m	267.22	27.24	18309
D=1.5m	0.13MPA	0.9m	122.63	12.5	8402
		0.8m	143.03	14.58	9800
		0.7m	163.43	16.66	11198
		0.6m	183.94	18.75	12602
		0.5m	204.34	20.83	14000
		0.4m	224.75	22.91	15398
		0.3m	245.15	24.99	16797
		0.2m	267.81	27.3	18349
D=1.8m	0.11MPA	1.1m	120.96	12.33	8287
		1.0m	138.22	14.09	9470
		0.9m	155.59	15.86	10660
		0.8m	172.85	17.62	11843
		0.7m	190.22	19.39	13033
		0.6m	207.48	21.15	14216
		0.5m	224.75	22.91	15398
		0.4m	242.01	24.67	16581
		0.3m	259.38	26.44	17771
		0.2m	276.64	28.2	18954
D=2.0m	0.10MPA	1.2m	125.76	12.82	8617
		1.1m	141.46	14.42	9692
		1.0m	157.16	16.02	10768
		0.9m	172.85	17.62	11843
		0.8m	188.64	19.23	12925
		0.7m	204.34	20.83	14000

Cylindrical Marine Rubber Airbag Length 5-24m For Ship Lifting Landing
